Self-propelled crawler rotary tiller operation steps
Self-propelled crawler rotary tiller is an important agricultural machinery used for farmland cultivation. The following are the basic steps for operating a self-propelled crawler rotary tiller:
1. Preparation before starting
Before starting a self-propelled crawler rotary tiller, a series of inspections and preparations are required to ensure that the machine can operate normally and ensure the safety of the operator:
Check the fuel, cooling water, and engine oil: Make sure these fluids are at normal levels, and if any problems are found, they should be eliminated in time.
Warn people around: Remind them to pay attention to safety and stay away from the machine.
Check the gearbox shift handle: Make sure it is in the neutral position.
Check the rotary tiller clutch handle: Make sure it is in the disengaged position.
2. Start the machine
The process of starting a self-propelled crawler rotary tiller includes turning on the main power switch, adjusting the throttle handle, and starting the machine:
Turn on the main power switch: The main power switch is usually located below the battery at the lower right rear.
Adjust the throttle handle: Put it in the appropriate position.
Start the machine: Start the machine with the start key.
3. Operate the machine to travel
After starting, adjust the throttle size to select the appropriate driving speed as needed.
4. Rotary tillage operation
When performing rotary tillage operation, you need to pay attention to the following points4:
Starting: The working clutch should be engaged when the rotary tillage part is lifted. The unit can only start after the rotary tiller reaches the predetermined speed. After starting, it should be driven as slowly as possible to ensure the quality of operation and reduce the wear of machine parts.
Turning: It is prohibited to operate when turning at the end of the field. The rotary tiller should be raised to make the blade leave the ground, and the power throttle should be reduced to avoid damage to the blade. Sharp turns are strictly prohibited to prevent damage to related parts.
Reversing and transferring: When reversing, crossing the ridge and transferring the plot, the rotary tiller should be lifted to the highest position and the working clutch should be separated to avoid damage to the machine parts.
5. Precautions
When operating a self-propelled crawler rotary tiller, you also need to pay attention to the following points:
Listening and observing: During driving, pay attention to whether the rotary tiller has noise or metal knocking sound, and observe the soil crushing and tillage depth. If there is any abnormality, turn off the engine immediately, check and eliminate the fault before continuing the operation.
Avoid overloading: Excessive load on the rotary tiller will cause the tractor to emit black smoke and slip, and the forward speed of the unit should be reduced at this time.
The above are the basic operating steps and precautions for self-propelled crawler rotary tillers. Please be sure to strictly follow the operating procedures during operation to ensure safe operation.
